F60 4
Clean the hydraulic oil tank
- Remove plug in front draining hose (A).
Drain the oil into a collection pan.
- Open hydraulic oil tank, clean cover (B).
- Clean inside of the tank.
- Put cover (B) and draining hose plug
(A) back, replace the sealing ring.
Replace the filter when changing the oil.
Suction/return flow hydraulic filter
Carry out filter replacement according to the interval or the indicator lamp in the
operating panel!
- Remove cover mounting screws (A) and lift off cover.
- Disassemble the removed unit into:
Cover (B)
Seperating plate (C)
Filter (D)
Dirt trap (E)
- Clean the filter housing, cover, separating plate and dirt trap.
- Check the O-rings (F), replace if necessary.
- Coat the sealing surfaces and O-rings with clean operating fluid.
The filter must be bled following filter replacement!
