F60 3
1.2 Points of maintenance
Hydraulic oil tank
Check oil level on oil level / oil temperature
gauge
- Check hydraulic oil level and hydraulic oil
tank temperature through oil level / oil
temperature gauge (A).
- Top up oil if necessary.
- If all cylinders are retracted, the oil level
should be at the middle of the gauge.
For filling in the oil:
- Remove cap (B).
- Fill in oil through the filling opening until the oil level rises to the centre of the
sight glass (A).
- Screw cap (B) on again.
- Properly clean cap (B), remove the dust and dirt.
