D30 9
Hopper transport safeguard
Before transporting or in order to park
the paver finisher, the hopper halves
must be swung upwards and the
transport safeguards for the hopper must
be inserted on both sides of the vehicle.
1. Lock handle.
2. Lock pin.
3. Hopper.
— Push lock handle (1) to make lock pin
(2) insert hopper (3), then the hopper
is locked.
Without transport safeguards inserted, the hopper halves will slowly open. It’s
danger during transportation.
