F50 4
Engine lube oil system (2)
Check oil level
In case of correct oil level, the oil is between
the two notches of the dipstick (A).
Only check the oil level when the finisher is in
a horizontal position!
Too much oil in engine damages gaskets; too
little oil results in overheating and engine
destruction.
For filling in the oil:
- Remove cap (B).
- Fill up oil to correct level.
- Return cap (B).
- Use dipstick to check level again.
Oil change:
The oil drain screw is accessed via the
cover (C) in the vehicle's material tunnel:
Change the oil when the engine is at
operating temperature.
- Put a collecting container (20L or above)
beneath the drain screw (D).
- Remove the drain screw (D), slowly drain
the engine lube oil completely.
- Reinstall filler opening (B) with a new
seal and tighten properly.
- Fill in the specified quality of lube oil
through the filler opening (B) on the
engine until the oil level rises to the
correct mark on the dipstick (A).
