D30 23
Parking brake must be released to be
able to tow the machine.
- Release lock nut (2), screw threaded
dowel (3) into pump as far as possible
and secure with lock nut.
- Actuate lever (4) of hand pump until
sufficient pressure has been built up
and traction system brakes have been
released.
Only release the traction system brakes
when the machine is sufficiently secured
against accidental rolling or is already
properly connected to the towing vehicle
the maximum travel speed is 10 m/min
The maximum load of towing point200 KN.
Observe the towing instructions in
section "C11 transportation"!
