C11 14
Two high-pressure cartridges (6) are
located on both of the travel drive
pumps (5).
The following activities must be carried
out to activate the towing function:
- Loosen lock nuts (7) three turns.
On completion of the towing process,
restore the initial status.
- Attach the towing bar to the coupling
(8) located in the bumper.
Now carefully and slowly tow the paver
finisher out of the construction area.
Only ever tow the shortest distance to
the means of transport or the next
parking possibility.
The max. permissible towing speed is
10 m/min!
In hazardous situations, a towing speed
of 15 m/min is only permitted temporarily.
The max. permissible towing eye (8) load is 200 KN.
