D11 3
mode equals to the highest
speed in “AUTO” mode.
To work in “AUTO” mode, drive
lever must be put into forward
2 Horn
Press in case of emergencies
and to indicate when the
vechicle starts to move!
The horn can also be used to
communicate
acoustically with
truck deliver for material
loading!
3 Auger right
Pushbutton function:
- Right auger manually or
automatically conveying
outwards.
For triggering auger function,
auger pushbutton function must
be switched to “AUTO” or
“MANUAL”.
Auger speed under “MANUAL”
mode equals to the highest
speed under “AUTO” mode.
To work under “AUTO” mode,
drive lever must be put into
forward postion.
4 Steering potentiometer
The steering wheel movement
is transferred
electrohydraulically.
For precise adjustments
(position “0” = straight-ahead)
For turning function, each side
(left/right) has 8 gears can be
adjusted.
