Power requirements
24
[4] Power requirements
The unit can operate from an AC power source (AC100-240V), built-in batteries or an external DC power
source (DC12/24V).
Whenever the power cord is not connected to a power outlet, or the power supply from an AC
power source (AC100-240V) or an external DC power source (DC12/24V) is shut down, the
power is automatically supplied from the built-in batteries.
J
Memory function
Preselected settings are retained in memory even if the power supply is interrupted. When the power supply
is resumed, the settings that were selected before the power supply interruption will be displayed.
4-1.
Power Outlet and Grounding
The following power supply ratings are available. Do not connect the unit to any other power
source.
Voltage - AC100-240V; power consumption - 220VA; frequency - 50/60Hz; operating voltage
range - AC100-240V±10%
Voltage - DC12V; current - 13A; operating voltage range - DC12.4-15.1V
Voltage - DC24V; current - 6.5A; operating voltage range - DC24.8-30.3V
The power outlet should be located near the unit in order to prevent accidental contact with a
trailing power cord. Use a separate power outlet for each unit.
Do not put many loads on one power outlet.
In order to complete the ground connection, only connect the power cord to a correctly ground-
ed 3-prong power outlet.
Do not operate the unit if you have any doubts about its ground connection.
Peripheral electrical equipment must also be grounded securely.
