MAINTENANCE
Cleaning and Disinfection
73
(5) Remove the hood inner panel.
Inner panel
(6) Remove the lighting lamp from the inner panel.
(7) Turn and remove the knob, then remove stiffener
B from the inner panel.
Lighting lamp
Knob
Stiffener B
(8) Disinfect the removed parts.
Parts that are to
be cleaned by
immersing them
in a disinfectant
solution
Tube introduction slit packing
Snap-open access port packing
Oxygen sensor attaching port
packing
Parts that are to
be cleaned
using a soft cloth
that has been
soaked in a
disinfectant
solution and
wrung out
Inner and outer faces of hood
Admittance panel
Inner panel
Lighting lamp
Knob
Stiffener B
To Next Page
