AuCom EMX4i - 9.20 32 Pressure Protection

PROGRAMMABLE PARAMETERS
710-14888-00C EMX4i User Manual 103
31D – Flow Response Delay
Range:
00:00:10 - 30:00:00 mm:ss:ms
Default:
00:00:500 ms
Description:
Sets a delay between the flow passing the high or low flow trip
levels, and the soft starter tripping.
9.20 32 Pressure Protection
NOTE
The parameters in this group are only active if a smart card is installed.
Pressure protection uses terminals B23, B24 or C33, C34, C43, C44 on the smart
card.
32A – High Pressure Trip Level
Range:
0 – 5000
Default:
10
Description:
Sets the trip point for high pressure protection.
32B – High Pressure Start Delay
Range:
00:00:10 – 30:00:00 mm:ss:ms
Default:
00:00:500 ms
Description:
Sets a delay before a high pressure protection trip can occur.
The delay is counted from the time a start signal is received. The
pressure is ignored until the start delay has elapsed.
32C – High Pressure Response Delay
Range:
00:00:10 – 30:00:00 mm:ss:ms
Default:
00:00:500 ms
Description:
Sets a delay between the pressure passing the high pressure
trip level, and the soft starter tripping.
32D – Low Pressure Trip Level
Range:
0 – 5000
Default:
5
Description:
Sets the trip point for low pressure protection.
32E – Low Pressure Start Delay
Range:
00:00:10 – 30:00:00 mm:ss:ms
Default:
00:00:500 ms
Description:
Sets a delay before a low pressure protection trip can occur. The
delay is counted from the time a start signal is received. The
pressure is ignored until the start delay has elapsed.
32F – Low Pressure Response Delay
Range:
00:00:10 – 30:00:00 mm:ss:ms
Default:
00:00:500 ms
Description:
Sets a delay between the pressure passing the low pressure trip
level, and the soft starter tripping.
