AuCom EMX4i - 9.22 34 Depth Protection

PROGRAMMABLE PARAMETERS
710-14888-00C EMX4i User Manual 105
9.22 34 Depth Protection
NOTE
The parameters in this group are only active if a smart card is installed.
Depth protection uses terminals B13, B14 or C13, C14 on the smart card.
34A – Depth Trip Level
Range:
0 – 1000
Default:
5
Description:
Sets the trip point for depth protection.
34B – Depth Reset Level
Range:
0 – 1000
Default:
10
Description:
Sets the level for the soft starter to auto-reset a depth trip.
34C – Depth Start Delay
Range:
00:00:10 – 30:00:00 mm:ss:ms
Default:
00:00:500 ms
Description:
Sets a delay before a depth protection trip can occur. The delay
is counted from the time a start signal is received. The depth
input is ignored until the start delay has elapsed.
34D – Depth Response Delay
Range:
00:00:10 – 30:00:00 mm:ss:ms
Default:
00:00:500 ms
Description:
Sets a delay between the depth passing the depth protection trip
level, and the soft starter tripping.
9.23 35 Thermal Protection
NOTE
The parameters in this group are only active if a smart card is installed.
35A – Temperature Sensor Type
Options:
None (default)
PT100
Description:
Selects which type of sensor is associated with the temperature
sensor input on the smart card.
35B – Temperature Trip Level
Range:
0° – 240°
Default:
40°
Description:
Sets the trip point for temperature protection. Use parameter
10B
Temperature Scale to configure the temperature scale.
