7.4 Starter status LEDs
Ready Run
Trip
Local
17694.
A
LED
name
On
Flashing
Ready
The motor is stopped and the
starter is ready to start.
The motor is stopped and the
starter is not ready to start:
• waiting for the
Restart Delay
(parameter 5P)
• the thermal models indicate the
starter and/or motor are too hot
to start safely
• the reset input (10, 11) is open
Run
The motor is in run state (receiving
full voltage).
The motor is starting or stopping.
Trip
The starter has tripped.
The starter is in warning state.
Local
The starter is being controlled via
a remote keypad.
–
If all LEDs are off, the starter is not receiving control voltage.
7.5 Displays
The keypad displays a wide range of performance information about the soft starter.
To scroll through the feedback screens, press the
and buttons.
Starter information
At power-up, the starter information screen shows details of the starter's rating,
software versions and serial number.
Welcome
01.01/01.00/01.00
Software versions: user interface, motor control, remote keypad
EMX4i-0069B-V5-S1-C1
Model code: current rating, mains voltage, frame size, control voltage
(remote keypad software version is only displayed when a remote
keypad is connected)
Starter status screen
69.0 A
motor running current
Running
Starter status
69.0 A 415 V
Parameters 10H User Parameter 1 and 10I User Parameter 2
