SETUP TOOLS
34 EMX4i User Manual 710-14888-00C
5. Setup Tools
Setup Tools includes options to load or save parameters to a backup file, set the
starter's network address, check the status of the inputs and outputs, reset the
thermal models or test operation using the Run Simulation.
To access the Setup Tools, press
to open the Menu then select Setup Tools.
5.1 Set Date and Time
To set the date and time:
1. Press
to open the menu then select Setup Tools.
2. Scroll to Set Date & Time.
3. Press the
button to enter edit mode.
4. Press the
and buttons to select which part of the date or time to edit.
5. Use the
and buttons to change the value.
6. Press
after the last digit to save the setting. When the action has been
completed, the screen will briefly display a confirmation message, then
return to the previous menu level.
5.2 Command Source
The EMX4i can be started and stopped via the digital inputs, remote keypad,
communication network, smart card or scheduled auto-start/stop. The command
source can be set via the Setup Tools, or using parameter 1A
Command Source
.
If the remote keypad is installed, the
button provides shortcut
access to the Command Source function in Setup Tools.
5.3 Commissioning
Commissioning lets the starter be started and stopped via the local keypad. Use the
and buttons to select a function, then press to send the selected
command to the starter. The available functions are:
• Quick stop (coast to stop)/Reset
• Start
• Stop
