PROGRAMMABLE PARAMETERS
100 EMX4i User Manual 710-14888-00C
20E – Screen Timeout
Options:
1 minute (default) 4 minutes
2 minutes 5 minutes
3 minutes
Description:
Sets the timeout for the menu to automatically close if no
keypad activity is detected.
20F – Motor Connection
Options:
Auto-detect (default)
In-line
Inside delta
Description:
Selects whether the soft starter will automatically detect the
format of the connection to the motor.
9.18 30 Pump Input Configuration
NOTE
The parameters in this group are only active if a smart card is installed.
30A – Pressure Sensor Type
Options:
None (default)
Switch
Analog
Description:
Selects which type of sensor is associated with the pressure
sensor input on the smart card.
30B – Pressure Units
Options:
Bar
kPa (default)
Psi
Description:
Selects which units the sensor will use to report the measured
pressure.
30C – Pressure at 4 mA
Range:
0 – 5000
Default:
0
Description:
Calibrates the soft starter to the 4 mA (0%) level of the pressure
sensor input.
30D – Pressure at 20 mA
Range:
0 – 5000
Default:
0
Description:
Calibrates the soft starter to the 20 mA (100%) level of the
pressure sensor input.
