KEYPAD AND FEEDBACK
710-14888-00C EMX4i User Manual 45
Current
The current screen shows real-time line current on each phase.
Phase Currents
000.0A 000.0A 000.0A
Last Start Information
The last start information screen shows details of the most recent successful start:
• start duration (seconds)
• maximum start current drawn (as a percentage of motor full load
current)
• calculated rise in motor temperature
Last start 010 s
350 % FLC
∆
Temp 5%
User configurable screen
The programmable screen can be configured to show the most important
information for the particular application. Use parameters 10J ~ 10M to select
which information to display.
Mains Frequency 59.7 Hz
Motor pf 1.01
Motor Power 37.0 kW
Motor Temp 85%
Date and Time
The date/time screen shows the current system date and time (24 hour format). For
details on setting the date and time, refer to
Set Date and Time on page 34.
Performance Graph
The performance graph provides a real-time display of operating performance.
Use parameters 10B~10E to format the graph.
The display on the main keypad shows information for motor current.
05050.C
0
00.0 A 0-
400%
If a remote keypad is connected, press
ALT
to change the graph data. The graph can
show:
• motor current
• motor temperature
• motor pf
• analog input data from the smart card (if installed)
