AUDAC M2 User Manual

34
ASingle-Ended/BalancedandanAntiphaseselectionbuttonareprovidedbelowtheMono
/Stereoselectionbutton.WhentheSingle-endedoptionhasbeenselected,aboostof+6
dBwillbeenabledformaintainingthesameconstantaudiolevelthroughoutthesystem,
comparedtoBalancedoutputconnections.UsingtheAntiphaseoption,theoutputsignal
rotatesover180°forapplicationswhereacontraryphaseisdesirable.
TheEqualizerandFilterfunctionsoftheoutputsaresimilartotheinputs.Theequalizer
isselectablebetweenthree and seven bandswithadjustable center frequency and
Q-factor,whilethefilterisselectablebetweenLow-Pass, High-Pass and Band-Pass
withvariable frequencies.FormoreinformationabouttheEqualizerandfilterconfiguration,
refertotheInputconfigurationwhichhasbeendescribedearlierinthismanual.
ADelay whichcanbeadjustedinstepsof1msinarangebetween0msto2000ms(2s)
canbeenabledonalloutputsoftheM2.Itcanbeadjustedbymovingthecorresponding
faderupanddown.Thedelaytimeisindicatedinmillisecondsontopofthefaderandthe
audiotransmissiondistanceinmetersisshownaccordinglywiththedelaytime.
UsingtheMaximum Volumefader,thevolumeforeachoutputcanbelimitedatacertain
level.Thedefaultvalueissetto0dBandcanbeadjustedbymovingthecorrespondingfader
upanddown.Whenadjustedtoadifferent(lower)value,themaximumoutputvolumefor
thiszonewillbelimitedattheselectedlevel.
Quick Menu Settings
The‘QuickMenuSettings’windowallowsyoutomakeaselectionoutofalltheavailable
inputsignalsforthe‘QuickSelectionMenu’.Thisisthedropdownlistmenuwhichis
displayedjustbelowthezonename.Itisconvenienttoaddthe8mostcommonusedand
importantscenestothe‘QuickSelectionMenu’.
Moreover,theinputs/scenesselectedinthismenuarealsothe8signalswhichare
selectablebytheDW3020/4020wallpanelswhicharelinkedwiththisoutput.
M2 Quick Menu Settings

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
