AUDAC M2 User Manual

40
Theleftsideofthewindowshowsa‘Trigger’and‘Input’dropdownlist.
The“Trigger”dropdownlistshowsallinputsonwhichtheprioritycanbetriggered,
includingtheDirectinputs,WallPanelinputs,Fiberinputs,Allcontactinputsandpriority
audioinputs.Herebythesignalonwhichthepriorityshouldbetriggeredcanbeselected.
Whenacontactinputisselected,theprioritywillbetriggeredwhenaconnectionhas
beenmadebetweentheselectedtriggercontact.Incaseanaudioinputhasbeen
selected,theprioritywillbetriggeredatthepresenceofanaudiosignalontheselected
input.
The‘Input’dropdownlistshowsallinputswhichcanbepatchedincaseapriority
situationoccurs.ThisincludesallDirectinputs,WallPanelinputs,Fiberinputsandpriority
audioinputs.
Therightsideofthewindowshowsalloutputssoyoucaneasilyselecttowhichofthem
theprioritysignalshouldbepatched,incaseofaprioritysignal.Thiscansimplybedone
byclickingthecorrespondingbutton.Usingthedropdownlist,thevolumeforthepriority
messagecanbesetinstepsof1dB.
A‘SwitchRelay’buttonisprovidedforeveryoutput.Bymeansofthisbuttoncanbe
selectedwhethertherelayforthecorrespondingoutputshouldswitchautomaticallyifa
prioritycallismadeonthisoutput.Thiscanbeusefulforbypassingexternal100Vvolume
controllers,activatingemergencylights,...
TheswitchingtoandfromaprioritysignalisdoneaccordingtotheHARDIN - FADEOUT
principle.ThismeansthatwhenaprioritysituationoccurstheM2immediatelyswitches
totheselectedpriorityaction.Whentheprioritysituationisover,thestatuswillreturn
backtothepreviousstatusbyfadingthesoundin.
M2 Priority Settings

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
