AudioCodes Mediant MSBR Series Configuration Guide

Version 6.8 135 Mediant MSBR
Configuration Guide 21. IP Multicast – PIM Sparse Mode
MSBR# show data ip mroute detail
Iif - Incoming interface, Oif - Outgoing interface
Origin Group Iif Pkts Bytes Wrong
Oifs:TTL
192.168.10.3 232.0.0.42 VLAN 1 36 27360 0
Fiber 0/1:1 PIM:1
MSBR# show data ip pim groups
Multicast Group Routing Table - Legend:
----
Flags:
SPT Shortest Path Tree, internal interface toward source
WC (*,G) entry
RP internal interface iif toward RP
CACHE a mirror for the kernel cache
SG (S,G) pure, not hanging off of (*,G)
CLONE_SG clone (S,G) from (*,G) or (*,*,RP)
----
Multicast Group Routing Table
Source Group RP addr Flags
---------------------------(*,G)----------------------------
INADDR_ANY 232.0.0.42 200.0.0.2 WC RP
Joined oifs: Fiber 0/1
Pruned oifs:
Leaves oifs:
Asserted oifs:
Outgoing oifs: Fiber 0/1
Incoming : PIM_FORWARDING
TIMERS: Entry Joine-Prune Register-Suppression Assert
165 20 0 0
VLAN 1 : 0
Fiber 0/1 : 165
GigabitEthernet 0/0 : 0
PIM_FORWARDING : 0
Source Group RP addr Flags
---------------------------(S,G)----------------------------
192.168.10.3 232.0.0.42 200.0.0.2 SPT CACHE SG
Joined oifs: Fiber 0/1 PIM_FORWARDING
Pruned oifs:
Leaves oifs:
Asserted oifs:
Outgoing oifs: Fiber 0/1 PIM_FORWARDING
Incoming : VLAN 1
TIMERS: Entry Joine-Prune Register-Suppression Assert
180 30 0 0
VLAN 1 : 0
Fiber 0/1 : 180
