(config-data)# route-map <name>
vrf
vrf-name
Associates a route-map with a VRF.
(config-data)# router ospf|bgp|rip
vrf vrf-name
Associates a BGP/OSPF/RIP routing-instance
with a VRF.
Also the show commands of the above configurations and the following utilities: Ping,
Traceroute, Copy files, debug capture data physical, show data mac table.
14.1.2 VRF App Awareness
The MSBR VRF App awareness is essentially the ability to perform ICMP commands (such
as ping, and traceroute) with a vrf attribute, enabling VRF-specific reachability and
connectivity testing. Note that ICMP packets are not routed from one VRF to another.
The operation is performed according to the ICMP ping and traceroute command syntax,
for example:
MSBR# ping 192.168.0.1 source data vrf blue
4 packets transmitted, 0 packets received
MSBR#
