AudioCodes Mediant MSBR Series Configuration Guide

IP Networking Configuration
Configuration Guide 98 Document #: LTRT-31657
16.1.2.1 Configuration
MSBR(config-data)# ip access-list VLAN1_IN permit ip any any log
MSBR(config-data)# ip access-list VLAN2_IN permit ip any any log
MSBR(config-data)# ip access-list VLAN3_IN permit ip any any log
MSBR(config-data)# qos match-map input QOS_VOIP vlan 1
MSBR(conf-m-map)# match access-list VLAN1_IN
MSBR(conf-m-map)# set queue VoIP
MSBR(conf-m-map)# exit
MSBR(config-data)# qos match-map input QOS_IT vlan 2
MSBR(conf-m-map)# match access-list VLAN2_IN
MSBR(conf-m-map)# set queue IT
MSBR(conf-m-map)# exit
MSBR(config-data)# qos match-map input QOS_USR vlan 3
MSBR(conf-m-map)# match access-list VLAN3_IN
MSBR(conf-m-map)# set queue USR
MSBR(conf-m-map)# exit
MSBR(config-data)# qos service-map gigabitethernet 0/0 output
MSBR(conf-s-map)# queue default
MSBR(conf-s-map-q)# priority 4
MSBR(conf-s-map-q)# exit
MSBR(conf-s-map)# queue VoIP
MSBR(conf-s-map-q)# priority 1
MSBR(conf-s-map-q)# bandwidth percent 40
MSBR(conf-s-map-q)# exit
MSBR(conf-s-map)# queue IT
MSBR(conf-s-map-q)# priority 2
MSBR(conf-s-map-q)# bandwidth percent 40
MSBR(conf-s-map-q)# exit
MSBR(conf-s-map)# queue USR
MSBR(conf-s-map-q)# priority 3
MSBR(conf-s-map-q)# bandwidth percent 20
MSBR(conf-s-map-q)# exit
MSBR(conf-s-map)# exit
MSBR(config-data)#
16.1.2.2 Output
MSBR# show data qos match-map
match-map input QOS_VOIP vlan 1
match access-list VLAN1_IN
set queue VOIP
match-map input QOS_IT vlan 2
match access-list VLAN2_IN
set queue IT
match-map input QOS_USR vlan 3
match access-list VLAN3_IN
set queue USR
MSBR#
