AudioCodes Mediant MSBR Series Configuration Guide

IP Networking Configuration
Configuration Guide 92 Document #: LTRT-31657
15.1.2.1 Configuration

MSBR1:
MSBR1# conf d
MSBR1(config-data)# int gigabitethernet 0/0
MSBR1(conf-if-GE 0/0)# ip address 180.1.1.1 255.255.255.0
MSBR1(conf-if-GE 0/0)# no firewall enable
MSBR1(config-data)# int vla 1
MSBR1(conf-if-VLAN 1)# ip address 192.168.11.1 255.255.255.0
MSBR1(conf-if-VLAN 1)# exit
MSBR1(config-data)# int vla 2
MSBR1(conf-if-VLAN 2)# ip address 192.168.12.1 255.255.255.0
MSBR1(conf-if-VLAN 2)# no shutdown
MSBR1(conf-if-VLAN 2)# exit
MSBR1(config-data)# int vla 3
MSBR1(conf-if-VLAN 3)# ip address 192.168.13.1 255.255.255.0
MSBR1(conf-if-VLAN 3)# no shutdown
MSBR1(conf-if-VLAN 3)# exit
MSBR1(config-data)# interface gre 1
MSBR1(conf-if-GRE 1)# ip address 1.1.1.1 255.255.255.0
MSBR1(conf-if-GRE 1)# tunnel destination 180.1.1.2
MSBR1(conf-if-GRE 1)# no shutdown
MSBR1(conf-if-GRE 1)# exit
MSBR1(config-data)# ip route 192.168.1.0 255.255.255.0 gre 1
MSBR1(config-data)# ip route 192.168.2.0 255.255.255.0 gre 1
MSBR1(config-data)# ip route 192.168.3.0 255.255.255.0 gre 1

MSBR2:
MSBR2# conf d
MSBR2(config-data)# int gigabitethernet 0/0
MSBR2(conf-if-GE 0/0)# ip address 180.1.1.2 255.255.255.0
MSBR2(conf-if-GE 0/0)# no firewall enable
MSBR2(config-data)# int vla 1
MSBR2(conf-if-VLAN 1)# ip address 192.168.1.1 255.255.255.0
MSBR2(conf-if-VLAN 1)# exit
MSBR2(config-data)# int vla 2
MSBR2(conf-if-VLAN 1)# ip address 192.168.2.1 255.255.255.0
MSBR2(conf-if-VLAN 1)# no shutdown
MSBR2(conf-if-VLAN 1)# exit
MSBR2(config-data)# int vla 3
MSBR2(conf-if-VLAN 1)# ip address 192.168.3.1 255.255.255.0
MSBR2(conf-if-VLAN 1)# no shutdown
MSBR2(conf-if-VLAN 1)# exit
MSBR2(config-data)# interface gre 1
MSBR2(conf-if-GRE 1)# ip address 1.1.1.2 255.255.255.0
MSBR2(conf-if-GRE 1)# tunnel destination 180.1.1.1
MSBR2(conf-if-GRE 1)# no shutdown
MSBR2(conf-if-GRE 1)# exit
MSBR2(config-data)# ip route 192.168.11.0 255.255.255.0 gre 1
MSBR2(config-data)# ip route 192.168.12.0 255.255.255.0 gre 1
MSBR2(config-data)# ip route 192.168.13.0 255.255.255.0 gre 1
