IP Networking Configuration
Configuration Guide 136 Document #: LTRT-31657
GigabitEthernet 0/0 : 0
PIM_FORWARDING : 0
Source Group RP addr Flags
--------------------------(*,*,RP)--------------------------
Number of Groups: 1
Number of Cache MIRRORs: 1
show data ip pim interfaces
Virtual Interface Table - Flag Legend:
----
DOWN Kernel state of interface
DISABLED Administratively disabled
DR Specified interface is the designated router
NO-NBR No PIM neighbors on virtual interface
PIM PIM neighbor on virtual interface
DVMRP DVMRP neighbor on virtual interface
----
Virtual Interface Table
Vif Local address Interface Thresh Flags
Neighbors (Expire)
0 192.168.0.1 BVI 1 1 DR
NO-NBR
2 10.31.2.86 GigabitEthernet 0/0 1
DISABLED
3 200.0.0.1 Fiber 0/1 1 PIM
200.0.0.2 (00:01:30)
MSBR# show data ip pim rp
RP address Interface Group prefix Priority
Holdtime (Seconds)
200.0.0.2 Fiber 0/1 224.0.0.0/4 1
65535
21.2.3 Multicast Example - Static RP
The concept of setting a static RP involves forcing the PIM protocol to use a specific IP
address as the Rendezvous Point.
Use
“ip multicast-routing” to enter the multicast routing configuration mode and
activate the PIM protocol on the MSBR system.
ip multicast-routing
mode pim
exit
Next, each interface that is used for multicast traffic should be specifically turned on:
interface Fiber 0/1
ip pim sparse-mode
exit
Setting static RP – the join-group packet will be sent to the RP IP address, in case the RP
support the desired group – multicast streaming will be performed.
