AudioCodes Mediant MSBR Series Configuration Guide

IP Networking Configuration
Configuration Guide 74 Document #: LTRT-31657
11.4.3.2 Output
MSBR1# show data ip route
Codes: K - kernel route, C - connected, S - static,
R - RIP, O - OSPF, B - BGP
C 10.10.10.20/32 is directly connected, Fiber 0/1
C 192.168.0.0/24 is directly connected, VLAN 1
C 20.20.20.0/24 is directly connected, GigabitEthernet 0/0
C 10.10.10.0/24 is directly connected, Fiber 0/1
default [42] via 10.10.10.20, Fiber 0/1 [IPSec]
B 0.0.0.0/0 [1/0] via 20.20.20.20, GigabitEthernet 0/0,
00:00:30
MSBR1#
Note: If and when the main link fails, the default route learned through BGP is erased
from the routing table and IPSec is then used as a gateway of last resort. This can be
observed, for example, using Traceroute, which shows that the next-hop is through
IPsec.
The following shows the Routing table after the change:
MSBR1# show data ip route
Codes: K - kernel route, C - connected, S - static,
R - RIP, O - OSPF, B - BGP
C 10.10.10.20/32 is directly connected, Fiber 0/1
C 192.168.0.0/24 is directly connected, VLAN 1
C 20.20.20.0/24 is directly connected, GigabitEthernet 0/0
C 10.10.10.0/24 is directly connected, Fiber 0/1
default [42] via 10.10.10.20, Fiber 0/1 [IPSec]
MSBR1#

AudioCodes Mediant MSBR Series Specifications

General

Product Series	Mediant MSBR Series
Category	Network Router
VoIP Protocols	SIP, H.323
Fax Support	T.38, G.711 pass-through
Integrated Firewall	Yes
VPN Support	IPSec, L2TP, PPTP
Management	Web GUI, CLI, SNMP, TR-069
FXS Ports	Up to 8
FXO Ports	Up to 2
Voice Codecs	G.711, G.729, G.723.1
Router Features	NAT, DHCP, QoS
Security Features	Firewall, DoS protection
Redundancy	Optional
Dimensions	1U Rack Mountable
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70 °C
Humidity	Up to 95% non-condensing
