Page #73 background imageLoading...
Page #73 background image
Version 6.8 73 Mediant MSBR
Configuration Guide 11. Dynamic IP Routing
ip dns server static
napt
no firewall enable
no shutdown
exit
interface Fiber 0/1
ip address 10.10.10.10 255.255.255.0
mtu auto
desc "WAN Fiber"
no service dhcp
ip dns server static
crypto map MAP1
no firewall enable
no shutdown
exit
interface VLAN 1
ip address 192.168.0.1 255.255.255.0
exit
router bgp 60001
bgp router-id 20.20.20.10
network 20.20.20.0/24
neighbor 20.20.20.20 remote-as 60002
neighbor 20.20.20.20 default-originate
distance bgp 1 1 1
exit
11.4.3.1.1 ISP1
ISP1 is used for BGP connectivity and therefore, it is configured accordingly for BGP
peering with the MSBR over the GigabitEthernet interface, and propagates a default route
to the MSBR.
11.4.3.1.2 ISP2
ISP2 is used to set up an IPSec tunnel over the Fiber interface, for security and
redundancy reasons. The IPSec configuration on the ISP2, in terms of key, authentication
and encryption matches with the IPSec configuration on the MSBR.
