AudioCodes Mediant MSBR Series Configuration Guide

Version 6.8 85 Mediant MSBR
Configuration Guide 14. Virtual Routing and Forwarding (VRF)
14 Virtual Routing and Forwarding (VRF)
VRF is an IP feature that is included in IP network routers, which allows the simultaneous
existence and work of multiple routing tables on a single physical router. This can be
visualized, in general and simple terms, as several logical routers inside a physical one.
Because of this separation to different routing and forwarding tables, this feature allows the
creation of different networks and segments without using multiple devices, creation of
VPNs, and isolation of different network segments for better security due to the fact that no
data is transferred from one VRF to another, and much more.
In addition, to utilize this separation of routing and forwarding tables, many components
and configuration objects can be associated with different VRFs on the same device, such
as physical and logical interfaces, static routes, prefix-lists and routing protocol instances.
On the MSBR's MAIN-VRF by default, BGP, OSPF, RIP services exist. The MSBR
supports up to five additional VRFs. For all additional VRFs, the user can enable up to five
dynamic routing services. For example, if VRF “BLUE” has BGP enabled towards the
WAN and RIP towards the LAN, the other VRFs will have cumulatively only three services
remaining for use.
14.1.1 VRF Configuration
The following describes the VRF configuration commands.
14.1.1.1 Global Configuration
Command Description
MSBR# configure data
Enters the data configuration menu.
(config-data)# ip vrf
vrf-name
Creates a VRF instance.
(config-data)# ip vrf
vrf-name
enable <ospf/rip/bgp>
Enables a routing protocol on the VRF instance.
14.1.1.2 Interface Configuration
Command Description
MSBR# configure data
Enters the data configuration menu.
(config-data)# interface
int-name
Enters the interface configuration mode.
(conf-if-
name
)# ip vrf forwarding
vrf-name
Associates the interface with a specific VRF.
14.1.1.3 Other
Command Description
MSBR# configure data
Enters the data configuration menu.
(config-data)# ip route vrf
vrf-
name destination mask next-hop
interface
Associates a static route with a VRF instance.
(config-data)# ip prefix-list
list-name vrf vrf-name action
prefix/length
Associates a prefix-list with a VRF instance.
