AudioCodes Mediant MSBR Series Configuration Guide

Version 6.8 155 Mediant MSBR
Configuration Guide 22. IP Multicast – IGMP Proxy
exit
Next, enable igmp-proxy on a LAN interface and a WAN interface
interface GigabitEthernet 0/0
ip igmp enable-proxy
exit
interface VLAN 1
ip igmp enable-proxy
exit
Figure 22-1 Multicast Example – IGMP Proxy

PC IP – 192.168.2.3 is the rtp receiver

PC IP – 200.200.200.3 is the rtp transmitter.
Setting Multicast Streamer and Receiver using VLC player:
http://get.videolan.org/vlc/2.1.5/win32/vlc-2.1.5-win32.exe
The example below shows an implementation of media streaming using VLC on the client
side for receiving multicast traffic.
