The following is an example of the show run command for two MSBRs:

Master:
M500 *# show run
# Running Configuration M500
## VoIP Configuration
configure voip
interface network-dev 0
name "vlan 1"
activate
exit
interface network-if 0
ip-address 192.168.10.2
prefix-length 24
gateway 192.168.10.1
name "Voice"
primary-dns 192.168.10.1
underlying-dev "vlan 1"
activate
exit
media udp-port-configuration
udp-port-spacing 10
activate
exit
voip-network realm 0
name "DefaultRealm"
ipv4if "Voice"
port-range-start 4000
session-leg 6154
port-range-end 65530
is-default true
activate
exit
megaco naming
physical-start-num 0 0
physical-start-num 1 1
physical-start-num 2 1
physical-start-num 3 0
physical-start-num 4 0
activate
exit
tdm
pcm-law-select mulaw
activate
exit
exit
