MediaPack Analog Gateways 39 MP-1288
Hardware Installation Manual 5. Cabling the Device
2. Terminate the wires on the other end of the cable to your patch panel or distribution
frame. The wires are grouped in pairs with labels indicating the FXS channels (see
Figure 5-12). Make sure that you connect the wires according to the correct port
channels as labelled on the wires.
3. Connect your analog equipment to your patch panel or distribution frame, by plugging
their RJ-11 connectors into the RJ-11 sockets on the patch panel or distribution frame.
5.3.3 Connecting FXS Interfaces Directly to an MDF
If you are using your own third-party MDF, follow the instructions below.
Warning: To reduce noise interference, use a twisted pair Octopus cable that is
terminated on a metal-hooded 50-pin Telco connector.
ļ To connect FXS interfaces directly to an MDF:
1. Wire the 50-pin Telco connectors according to the pinouts in Table 5-2.
2. Connect the wire-pairs at the other end of the cable to a 50-pin male Telco connector
(not supplied).
3. Attach the male connector to one of the FXS blade's 50-pin female Telco connectors,
located on the chassis' rear panel.
