Version 7.2 1045 Mediant 1000B Gateway & E-SBC
User's Manual 62. Configuration Parameters Reference
Parameter Description
configure voip > gateway dtmf-supp-
service supp-service-settings > mwi-
subs-ipgrpid
[MWISubscribeIPGroupID]
Defines the IP Group ID used when subscribing to an MWI
server. The 'The SIP Group Name' field value of the IP
Groups table is used as the Request-URI host name in the
outgoing MWI SIP SUBSCRIBE message. The request is
sent to the IP address defined for the Proxy Set that is
associated with the IP Group. The Proxy Set's capabilities
such as proxy redundancy and load balancing are also
applied to the message.
For example, if the 'SIP Group Name' field of the IP Group is
set to "company.com", the device sends the following
SUBSCRIBE message:
SUBSCRIBE sip:company.com...
Instead of:
SUBSCRIBE sip:10.33.10.10...
Note: If the parameter is not configured, the MWI
SUBSCRIBE message is sent to the MWI server as defined
by the MWIServerIP parameter.
[NotificationIPGroupID] Defines the IP Group ID to which the device sends SIP
NOTIFY MWI messages.
Note:
 This is used for MWI Interrogation. For more information
on the interworking of QSIG MWI to IP, see Message
Waiting Indication on page 547.
 To determine the handling method of MWI Interrogation
messages, use the
TrunkGroupSettings_MWIInterrogationType, parameter
(in the Trunk Group Settings table).
configure voip > gateway dtmf-supp-
service supp-service-settings > mwi-
qsig-party-num
[MWIQsigMsgCentreldIDPartyNumber]
Defines the Message Centred ID party number used for
QSIG MWI messages. If not configured (default), the
parameter is not included in MWI (activate and deactivate)
QSIG messages.
The valid value is a string.
Digit Patterns The following digit pattern parameters apply only to voice mail applications that use
the DTMF communication method. For available pattern syntaxes, refer to the CPE Configuration
Guide for Voice Mail.
Forward on Busy Digit Pattern
(Internal)
configure voip > gateway voice-mail-
setting > fwd-bsy-dig-ptrn-int
[DigitPatternForwardOnBusy]
Defines the digit pattern used by the PBX to indicate 'call
forward on busy' when the original call is received from an
internal extension.
The valid range is a 120-character string.
Forward on No Answer Digit Pattern
(Internal)
configure voip > gateway voice-mail-
setting > fwd-no-ans-dig-pat-int
[DigitPatternForwardOnNoAnswer]
Defines the digit pattern used by the PBX to indicate 'call
forward on no answer' when the original call is received from
an internal extension.
The valid range is a 120-character string.
