Version 7.2 1083 Mediant 1000B Gateway & E-SBC
User's Manual 62. Configuration Parameters Reference
Parameter Description
(E_M_ImmediateTable.dat) protocol:
CASFileName_0 = 'E_M_WinkTable.dat'
CASFileName_1 = 'E_M_ImmediateTable.dat'
CASTableIndex_0 = 0
CASTableIndex_1 = 0
CASTableIndex_2 = 1
CASTableIndex_3 = 1
Note:
 You can define CAS tables per B-
channel using the parameter
CASChannelIndex.
 The x
in the ini file parameter name denotes the trunk number,
where 0 is Trunk 1.
Dial Plan
configure voip > interface e1-t1 >
cas-dial-plan-name
[CASTrunkDialPlanName_x]
Defines the CAS Dial Plan name per trunk.
The range is up to 11 characters.
For exam
ple, the below configures E1_MFCR2 trunk with a single
protocol (Trunk 5):
ProtocolType_5 = 7
CASFileName_0='R2_Korea_CP_ANI.dat'
CASTableIndex_5 = 0
DialPlanFileName = 'DialPlan_USA.dat'
CASTrunkDialPlanName_5 = 'AT_T'
Note: The x in the ini file parameter name
denotes the trunk number, where 0 is Trunk 1.
[CASFileName_x] Defines the CAS file name (e.g., 'E_M_WinkTable.dat') that
defines the CAS protocol, where x denotes the CAS file ID (0-7).
It is possible to define up to eight different CAS files by repeating
the parameter. Each CAS file can be associated with one or more
of the device's trunks, using the parameter CASTableIndex_x.
Note: For the parameter to take effect, a device reset is required.
CAS Table per Channel
configure voip > interface e1-t1 >
cas-channel-index
[CASChannelIndex]
Defines the loaded CAS protocol table index per B-channel
pertaining to a CAS trunk. The parameter is assigned a string
value and can be set in one of the following two formats:
 CAS table per channel: Each channel is separated by a
comma and the value entered denotes the CAS table index
used for that channel. The syntax is <CAS index>,<CAS
index> (e.g., "1,2,1,2…"). For this format, 31 indices must be
defined for E1 trunks (including dummy for B-channel 16), or
24 indices for T1 trunks. Below is an example for configuring a
T1 CAS trunk (Trunk 5) with several CAS variants:
ProtocolType_5 = 7
CASFILENAME_0='E_M_FGBWinkTable.dat'
CASFILENAME_1='E_M_FGDWinkTable.dat'
CASFILENAME_2='E_M_WinkTable.txt'
CasChannelIndex_5 =
‘0,0,0,1,1,1,2,2,2,0,0,0,1,1,1,0,1,2,0,2,1,2,2
,2’
CASDelimitersPaddingUsage_5 = 1
 CAS table per channel group: Each channel group is
separated by a colon and each channel is separated by a
comma. The syntax is <x-y channel range>:<CAS table
index>, (e.g., "1-10:1,11-31:3"). Every B-channel (including 16
