User's Manual 1084 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
Parameter Description
for E1) must belong to a channel group. Below is an example
for configuring an E1 CAS trunk (Trunk 5) with several CAS
variants:
ProtocolType_5 = 8
CASFILENAME_2='E1_R2D'
CASFILENAME_7= E_M_ImmediateTable_A-Bit.txt'
CasChannelIndex_5 = ‘1-10:2,11-20:7,21-31:2’
Note:
 To configure the parameter, the trunk must first be stopped.
 Only one of these formats can be implemented; not both.
 When the parameter is not configured, a single CAS table for
the entire trunk is used, configured by the parameter
CASTableIndex.
[CASTablesNum] Defines how many CAS protocol configurations files are loaded.
The valid range is 1 to 8.
Note: For the parameter to take effect, a device reset is required.
CAS State Machines Parameters
Note: To configure the CAS State Machine table using the Web interface, see ''Configuring CAS
State Machines'' on page 451. The CAS state machine can be configured only through the Web-
based management tool.
Generate Digit On Time
[CASStateMachineGenerateDigit
OnTime]
Generates digit on-time (in msec).
The value must be a positive value. The default is -1.
Generate Inter Digit Time
[CASStateMachineGenerateInter
DigitTime]
Generates digit off-time (in msec).
The value must be a positive value. The default is -1.
DTMF Max Detection Time
[CASStateMachineDTMFMaxOn
DetectionTime]
Detects digit maximum on time (according to DSP detection
information event) in msec units.
The value must be a positive value. The default is -1.
DTMF Min Detection Time
[CASStateMachineDTMFMinOnD
etectionTime]
Detects digit minimum on time (according to DSP detection
information event) in msec units. The digit time length must be
longer than this value to receive a detection. Any number may be
used, but the value must be less than
CasStateMachineDTMFMaxOnDetectionTime.
The value must be a positive value. The default is -1.
MAX Incoming Address Digits
[CASStateMachineMaxNumOfInc
omingAddressDigits]
Defines the limitation for the maximum address digits that need to
be collected. After reaching this number of digits, the collection of
address digits is stopped.
The value must be an integer. The default is -1.
MAX Incoming ANI Digits
[CASStateMachineMaxNumOfInc
omingANIDigits]
Defines the limitation for the maximum ANI digits that need to be
collected. After reaching this number of digits, the collection of
ANI digits is stopped.
The value must be an integer. The default is -1.
Collect ANI
[CASStateMachineCollectANI]
In some cases, when the state machine handles the ANI
collection (not related to MFCR2), you can enable the state
machine to collect ANI or discard ANI.

[0]
No = Don't collect ANI.
