Version 7.2 1091 Mediant 1000B Gateway & E-SBC
User's Manual 62. Configuration Parameters Reference
Parameter Description
Note: When using the ini file to configure the device to support
several ISDNOutCallsBehavior features, add the individual
feature values. For example, to support both [2] and [16]
features, set ISDNOutCallsBehavior = 18 (i.e., 2 + 16).
[ISDNOutCallsBehavior_x] Same as the description for parameter ISDNOutCallsBehavior,
but for a specific trunk ID.
ISDN NS Behaviour 2
configure voip > interface e1-t1|bri >
isdn-bits-ns-extension-behavior
[ISDNNSBehaviour2]
Bit-field to determine several behavior options that influence
the behavior of the Q.931 protocol.
 [8] NS BEHAVIOUR2 ANY UUI = Any User to User
Information Element (UUIE) is accepted for any protocol
discriminator. This is useful for interoperability with non-
standard switches.
 [16] NS BEHAVIOUR2 DISPLAY = The Display IE is
accepted even if it is not defined in the QSIG ISDN protocol
standard. This is applicable only when configuration is QSI.
 [64]
NS BEHAVIOUR2 FAC REJECT = When this bit is set,
the device answers with a Facility IE message with the
Reject component on receipt of Facility IE with
unknown/invalid Invoke component. This bit is implemented
in QSIG and ETSI variants.
[PSTNExtendedParams] Determines the bit map for special PSTN behavior parameters:
 [0] = (Default) Applicable for NI-2 ISDN and QSIG
"Networking Extensions". This bit (i.e., bit #0) is responsible
for the Invoke ID size:
If this bit is not set (default), then the Invoke ID size is
always one byte, with a value of 01 to 7f.
If this bit is set, then the Invoke ID size is one or two
bytes according to the Invoke ID value.
 [2] = Applicable to the ROSE format (according to the old
QSIG specifications). This bit (i.e., bit #1) is responsible for
the QSIG octet 3. According to the ECMA-165 new version,
octet 3 in all QSIG supplementary services Facility
messages should be 0x9F = Networking Extensions.
However, according to the old version, the value should be
0x91 = ROSE:
If this bit is not set (default): 0x9F = Networking
Extensions.
If this bit is set: 0x91 = ROSE.
 [3] = Use options [0] and [2] above.
Note: For the parameter to take effect, a device reset is
required.
BRI Parameters
BRI Layer 2 Mode
configure voip > interface bri > isdn-
layer2-mode
[BriLayer2Mode]
Defines Point-to-Point (P2P) or Point-to-Multipoint (P2MP)
mode for BRI ports.
 [0] Point to Point (default)
 [1] Point to Multipoint = Must be configured for Network
side.
configure voip > interface
Defines the BRI terminal endpoint identifier (TEI) when in
point-to-point (P2P) mode.
