Version 7.2 515 Mediant 1000B Gateway & E-SBC
User's Manual 24. Manipulation
2. Click New; the following dialog box appears (e.g., Redirect Number Tel-to-IP table):
Figure 24-4: Redirect Number Manipulation for Tel-to-IP Table (Example) - Add Dialog Box
3. Configure a manipulation rule according to the parameters described in the table
below.
4. Click Apply.
Table 24-5: Redirect Number Manipulation Tables Parameter Description
Parameter Description
General
Index
[_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
manipulation-name
[_ManipulationName]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 20 characters.
Match
Destination Prefix
dst-prefix
[_DestinationPrefix]
Defines the destination (called) telephone number prefix.
The default value is the asterisk (*) symbol (i.e., any number).
For manipulating the diverting and redirected numbers for call
diversion, you can use the strings "DN" and "RN" to denote the
destination prefix of these numbers. For more information, see
Manipulating Redirected and Diverted Numbers for Call Diversion on
page 518.
Redirect Prefix
redirect-prefix
[_RedirectPrefix]
Defines the redirect telephone number prefix.
The default value is the asterisk (*) symbol (i.e., any number prefix).
Source Trunk Group ID Defines the Trunk Group from where the Tel call is received.
