User's Manual 666 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
Parameter Description
Note:
 The parameter is applicable only if the 'Destination Type'
parameter is configured to IP Group.
 The selectable IP Group for the parameter depends on the
assigned Routing Policy (in the 'Routing Policy' parameter in
this table). For more information, see ''Configuring SBC
Routing Policy Rules'' on page 670.
Destination SIP Interface
dst-srd-id
[IP2IPRouting_DestSIPInterfaceNa
me]
Defines the destination SIP Interface to where the call is sent.
By default, no value is defined.
To configure SIP Interfaces, see ''Configuring SIP Interfaces''
on
page 326.
Note:
 The parameter is applicable only if the 'Destination Type'
parameter is configured to any value other than IP Group. If
the 'Destination Type' parameter is configured to IP Group,
the following SIP Interface is used:

Server-type IP Groups: SIP Interface that is assigned to
the Proxy Set associated with the IP Group.

User-type IP Groups: SIP Interface is determined during
user registration with the device.
 For multi-tenancy, if the assigned Routing Policy is not
shared (i.e., the Routing Policy is associated with an Isolated
SRD), the SIP Interface must be one that is associated with
the Routing Policy or with a shared Routing Policy (i.e., the
Routing Policy is associated with one or more Shared
SRDs). If the Routing Policy is shared, the SIP Interface can
be one that is associated with any SRD or Routing Policy
(but it's recommended that it belong to the same
SRD/Routing Policy or to shared SRD/Routing Policy to
avoid "bleeding").
Destination Address
dst-address
[IP2IPRouting_DestAddress]
Defines the destination address to where the call is sent. The
address can be an IP address or a domain name (e.g.,
domain.com).
If ENUM-based routing is used (i.e., the 'Destination Type'
parameter is set to ENUM) the parameter defines the IP
address or domain name (FQDN) of the ENUM service, for
example, e164.arpa, e164.customer.net or NRENum.net. The
device sends the ENUM query containing the destination phone
number to an external DNS server, configured in the IP
Interfaces table. The ENUM reply includes a SIP URI
(user@host) which is used as the destination Request-URI in
this routing table.
The valid value is a string of up to 50 characters (IP address or
FQDN). By default, no value is defined.
Note:
 The parameter is applicable only if the 'Destination Type'
parameter is set to Dest Address [1] or ENUM [3];
otherwise, the parameter is ignored.
 When using domain names, enter a DNS server IP address
or alternatively, define these names in the Internal DNS table
(see ''Configuring the Internal SRV Table'' on page 157).
 To terminate SIP OPTIONS messages at the device (i.e., to
