Page #74 background image
Please state device type and our order number (see name plate) when ordering spare parts. Only original AUMA spare parts should be used.
Failure to use original spare parts voids the warranty and exempts AUMA from any liability. Representation of spare parts may slightly vary
from actual delivery.
TypeDesignationRef. no.TypeDesignationRef. no.
Sub-assemblyHandwheel with ball handle542.0Sub-assemblyHousing001.0
Sub-assemblyOutput drive types B/B1/B2/B3/B4/C/E549.0Sub-assemblyBearing flange002.0
Sub-assemblyOutput drive sleeve B/B1/B2/B3/B4/C/E549.1Sub-assemblyHollow shaft003.0
Parallel key551.1Sub-assemblyDrive shaft005.0
Sub-assemblyMechanical position indicator553.0Motor coupling005.1
Sub-assemblySocket carrier for motor plug/socket con-
nector with cable harness
554.0Manual drive coupling005.3
Sub-assemblyPotentiometer as position transmitter556.0Worm wheel006.0
Sub-assemblyPotentiometer without slip clutch556.1Sub-assemblyManual gearing009.0
Heater557.0Sub-assemblyTorque lever017.0
Sub-assemblyBlinker transmitter including pins at wires
(without impulse disc and insulation plate)
558.0Gear segment018.0
Sub-assemblyElectromechanical control unit with
switches, including torque switching heads
559.01Crown wheel019.0
Sub-assemblyElectronic control unit with magnetic limit
and torque transmitter (MWG)
559.02Sub-assemblyDrive pinion II for torque switching022.0
Sub-assemblySwitch stack for direction OPEN560.01Sub-assemblyOutput drive wheel for limit switching023.0
Sub-assemblySwitch stack for direction CLOSE560.02Sub-assemblyDrive wheel for limit switching024.0
Sub-assemblySwitch for limit/torque560.1Sub-assemblyLocking plate025.0
Switch case for direction OPEN560.21Sub-assemblyCable for protective earth058.0
Switch case for direction CLOSE560.22Sub-assemblyMotor (only for V... motors incl. ref. no.
079.0)
070.0
Sub-assemblyRWG position transmitter566.0Sub-assemblyPlanetary gearing for motor drive (only for
V... motors)
079.0
Sub-assemblyPotentiometer for RWG without slip clutch566.1Sub-assemblyReduction gearing155.0
Sub-assemblyPosition transmitter board for RWG566.2Sub-assemblyCover500.0
Sub-assemblyCable set for RWG566.3Sub-assemblySocket carrier (complete with sockets)501.0
Sub-assemblySlip clutch for potentiometer567.1Sub-assemblyPin carrier without pins502.0
Stem protection tube (without cap)568.1Sub-assemblySocket for controls503.0
Protective cap for stem protection tube568.2Sub-assemblySocket for motor504.0
V-seal568.3Sub-assemblyPin for controls505.0
Threaded sleeve568.4Sub-assemblyPin for motor506.0
Stem nut A (without thread)575.1Sub-assemblyCover for electrical connection507.0
Sub-assemblyMotor coupling on motor shaft583.0Sub-assemblyThreaded plug511.0
Pin for motor coupling583.1Sub-assemblyOutput drive type A (without stem nut)514.0
Sub-assemblyRetaining spring for motor coupling584.0Sub-assemblyAxial needle roller bearing514.1
Sub-assemblyEWG position transmitter614.0Radial seal for output drive type A514.2
MWG 05.03 cover627.0Sub-assemblyOutput drive type D516.0
SetSeal kit, smallS1Output drive shaft D516.1
SetSeal kit, largeS2Snap ring535.1
Sub-assemblyScrew plug539.0
74
SA 07.2 SA 16.2 /SAR 07.2 SAR 16.2
Spare parts AM 01.1/AM 02.1
