Actuator controls AUMATIC AC 01.1 / ACExC 01.1
DeviceNet Operation instructions
36
ID in
EDS file
Description Class
ID
Instance
ID
Attribute
ID
Note
23 DN1 Analogue Input 1 Begin 103 1 51 Parameters for setting the analogue 0 – 20 mA
inputs of the DeviceNet interface
24 DN1 Analogue Input 1 End 103 1 52
25 DN1 Analogue Input 2 Begin 103 1 53
26 DN1 Analogue Input 2 End 103 1 54
33 Failure Behaviour 102 1 5 Parameters for setting the safety behaviour
34 Delay Time 102 1 6
35 Failure Position 102 1 7
36 Preset Position 102 1 8
37 Failure Source 102 1 24
38 Open Position 102 1 41 Parameters for setting the type of seating in
the end positions
39 Closed Position 102 1 51
40 Monitor Triggers 102 1 42 Parameters for setting the monitoring functions
41 Max. Starts/Hour 102 1 35
42 Max. Duty Cycle 102 1 36
43 Max. Run time 102 1 37
44 Adaptive Behaviour 102 1 87 Parameters for setting the positioner
45 Dead Time 102 1 10
46 Opening Stop Band 102 1 11
47 Closing Stop Band 102 1 12
48 Outer Dead Band 102 1 13
49 Intermed. Position 102 1 85
Parameters for setting the intermediate posi-
tions
50 Pos.1 102 1 68
51 Pos.1 Behaviour 102 1 69
52 Pos.1 Selector Switch 102 11 70
53 Pos.1 Control 102 1 71
54 Pos.2 102 1 72
55 Pos.2 Behaviour 102 1 73
56 Pos.2 Selector Switch 102 1 74
57 Pos.2 Control 102 1 75
58 Pos.3 102 1 76
59 Pos.3 Behaviour 102 1 77
60 Pos.3 Selector Switch 102 1 78
61 Pos.3 Control 102 1 79
62 Pos.4 102 1 80
63 Pos.4 Behaviour 102 1 81
64 Pos.4 Selector Switch 102 1 82
65 Pos.4 Control 102 1 83
66 Pos.5 103 1 19
67 Pos.5 Behaviour 103 1 20
68 Pos.5 Selector Switch 103 1 21
69 Pos.5 Control 103 1 22
70 Pos.6 103 1 23
71 Pos.6 Behaviour 103 1 24
72 Pos.6 Selector Switch 103 1 25
73 Pos.6 Control 103 1 26
74 Pos.7 103 1 27
75 Pos.7 Behaviour 103 1 28
76 Pos.7 Selector Switch 103 1 29
77 Pos.7 Control 103 1 30
78 Pos.8 103 1 31
Parameter s for setting the application functions of the AUMATIC (the meaning of the parameters is described in detail
in the operation instructions to the actuator “Multi-turn actuators SA .../part-turn actuators SG ... with AUMATIC AC“)
