AUMA Aumatic ACExC 01.1 User Manual

Actuator controls AUMATIC AC 01.1 / ACExC 01.1
Operation instructions DeviceNet
37
ID in
EDS file
Description Class
ID
Instance
ID
Attribute
ID
Note
79 Pos.8 Behaviour 103 1 32
80 Pos.8 Selector Switch 103 1 33
81 Pos.8 Control 103 1 34
82 Stepping Mode 102 1 84 Parameters for setting the stepping mode
83 Direction Open 102 1 25
84 On Time Open 102 1 26
85 Off Time Open 102 1 27
86 Start Step Open 102 1 28
87 Stop Step Open 102 1 29
88 Direction Close 102 1 30
89 On Time Close 102 1 31
90 Off Time Close 102 1 32
91 Start Step Close 102 1 33
92 Stop Step Close 102 1 34
93 Operational Data 102 1 62 Logging of operating data
94 Total Motor Runtime 102 1 100
95 Motor Runtime 102 1 101
96 Total Starts 102 1 102
97 Starts 102 1 103
98 Total TSC Stops 102 1 104
99 TSC Stops 102 1 105
100 Total LSC Stops 102 1 106
101 LSC Stops 102 1 107
102 Total TSO Stops 102 1 108
103 TSO Stops 102 1 109
104 Total LSO Stops 102 1 110
105 LSO Stops 102 1 111
106 Total No. Power On 102 1 122
107 No. Power On 102 1 123
108 Total TSC Faults 102 1 112
109 TSC Faults 102 1 113
110 Total TSO Faults 102 1 114
111 TSO Faults 102 1 115
112 Total Thermal Flt. 102 1 116
113 Thermal Faults 102 1 117
114 Total PE Faults 102 1 118
115 PE Faults 102 1 119
116 Tot. Wrn.Starts/Run1 102 1 120
117 Wrn.Starts/Run1 102 1 121
118 Tot.Wrn.Starts/Run2 102 1 124
119 Wrn.Starts/Run2 102 1 125
Parameters, which may only be viewed have a grey background.
