User Constructed Cables – Wiring Diagrams (cont’d)
Diagram 22
6–35
Chapter 6: PLC Communications
6
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
®
RD –
SD –
shield
Wiring Diagram
SD +
RD +
GND
TERM
Notes: Use the above wiring diagram to make your own cable. We recommend Belden 88102 shielded cable or equivalent/
EA-COMCON-3
SOLO Temperature Controller to C-more Micro-Graphic Panel (RS-485)
C-more Micro-Graphic
Serial Port2
DATA –
DATA +
SL4824 Series
11 12
RS 485
DATA +
DATA
SL4848 Series
9
10
RS 485
DATA
DATA +
SL4896 Series
SL9696 Series
1
2
RS 485
DATA
DATA +
User Constructed
