26 © Copyright Reserved Autonics Co., Ltd.
Category TM2 Series TM4 Series
Integral Time (I)
0 ~ 9999 sec.
Derivative Time (D)
0 ~ 9999 sec.
Control Period
0.1 ~ 120.0 sec. (Only relay and, SSR output type)
Manual Reset Value
0.0 ~ 100.0%
Sampling period
50 ms
(2 channel simultaneous sampling)
100 ms
(4 channel simultaneous sampling)
Dielectric Strength
1000 VAC, 50/60Hz for 1 minute (between power source terminal and input
terminal)
Vibration Resistance
5 to 55 Hz (1 min. interval), 0.75 mm double amplitude for 2 hours each in
X, Y, and Z directions.
Relay
Life
Cycle
Mechanical
Over 10,000,000 cycles
Electrical
Over 100,000 cycles (250VAC 3 A resistance load)
Insulation Resistance
100 MΩ (at 500VDC megger)
Noise Resistance
Square wave noise by noise simulator (pulse width 1μs) ±0.5 kV
Environment
Ambient
Temperature
-10~50℃, Storage temperature: -20~60℃
35~85%RH, Storage humidity: 35~85%RH
Accessories
Expansion connectors
Power supply/communications connector
(※Included with basic module only)
Insulation type
※
3
Approved Standards
CE, UL
Unit Weight
Approx. 135 to 152g Approx. 135 to 152g
※1: In case of thermocouple K, T, N, J, E at -100℃ below and L, U, Platinel II, it is 2℃±1
Digit Max. In case of thermocouple B, indicating accuracy cannot be ensured under 400℃.
In case of thermocouple R, S at 200℃ below and thermocouple C, G, it is 3℃±1Digit Max.
※2: Applied when used out of range 23±5℃.
※3: “ ” mark indicates that equipment protected throughout by double insulation or
reinforced insulation.
※Condition for use in environment is no freezing or condensation.
※Weights by model are shown in the following table.
Model Name Weight Model Name Weight Model Name Weight
TM2-22RB Approx. 144 g TM2-22CB Approx. 139 g TM4-N2RB Approx. 174 g
TM2-42RB Approx. 152 g TM2-42CB Approx. 148 g TM4-N2RE Approx. 166 g
TM2-22RE Approx. 135 g TM2-22CE Approx. 130 g TM4-N2SB Approx. 160 g
TM2-42RE Approx. 143 g TM2-42CE Approx. 139 g TM4-N2SE Approx. 152 g
