Autonics TM4 Series - DIN Rail Mounting

3 Dimensions
30 © Copyright Reserved Autonics Co., Ltd.
3.1.3 DIN Rail Mounting
(1) Installation/Removal method of a single module
1) Installation method
① Put the top edge of the rail lock on the top edge of the DIN rail.
② Push the module body in while pressing down.
2) Removal method
① Press down the module body.
② Pull the module body forward.
