Autonics TM4 Series User Manual

6 Parameter Settings and Functions
84 © Copyright Reserved Autonics Co., Ltd.
6.6 Additional Features
6.6.1 Monitoring Functionality
6.6.1.1 Control Output MV Monitoring
Monitors and displays the current control output MV.
6.6.1.1.1. Heating MV Monitoring.
 Displays the current heating MV during heating control or heating and cooling control.
 Users may manually adjust the MV to control the temperature.
 Measurement range: 0.0 ~ 100.0%
6.6.1.1.2. Cooling MV Monitoring
 Displays the current cooling MV during cooling control or heating and cooling control.
 Users may manually adjust the MV to control the temperature.
 Measurement range: 0.0 ~ 100.0%
6.6.1.2 Heater current monitoring.
 A feature that monitors and displays the current of a heater (load) being controlled by
control output.
 Measurement range: 0.0 to 50.0A
The current value of a heater (load) is measured and displayed
through the current transformer.
Group Parameter Range
Factory
Default
Unit
- Heating_MV 0.0 ~ 100.0 - %
- Cooling_MV 0.0 ~ 100.0 - %
- CT1_Heater Current 0.0 ~ 50.0 - A
- CT2_Heater Current 0.0 ~ 50.0 - A
