Autonics TM4 Series User Manual

6 Parameter Settings and Functions
© Copyright Reserved Autonics Co., Ltd. 69
Group Parameter Range Factory Default Unit
Alarm Setting Group Alarm Type
See above
table.
AL-A -
 You can set alarm output (Alarm 1 Type to Alarm 4 Type)
individually.
 If alarm output mode has been selected as LBA, SBA or HBA,
AL-C, AL-D modes are not available.
6.4.4 Alarm SV setting
You can set alarm output activation values. According to the selected alarm output mode,
configuration parameters (AL□.H/AL□.L) will be activated for each setting.
Group Parameter Range
Factory
Default
Unit
Alarm
Setting
Group
Alarm High_CH
Alarm Low_CH
Deviation alarm:
 By input type –F.S. to F.S.
Absolute value alarm:
 Within display range by input type
1550 ℃,℉
Changing the alarm output mode or options resets the settings to the
highest or lowest values that will not trigger output in the new mode.
6.4.5 Alarm Output Hysteresis Settings
“H” shown in the image from 6-4-2. Alarm Output Mode reresents the alarm output
hysteresis. It is used to set an interval between alarm output ON/OFF periods.
 Can be set individually by alarm output (Alarm 1 Type to Alarm 2 Type).
Group Parameter Range
Factory
Default
Unit
Alarm Setting
Group
Alarm Hysteresis_Ch
1 to 100
(Temperature H),
0.1 to 100.0
(Temperature L)
1 ℃,℉
 Alarm output hysteresis applies to heater burnout alarm (HBA)
in the same manner.
 This parameter does not appear if Loop Break Alarm (LBA) or
Sensor Break Alarm (SBA) is selected.
