6 Parameter Settings and Functions
46 © Copyright Reserved Autonics Co., Ltd.
6.1.2 Input Type Settings
This product supports multiple input types, making it possible for the user to choose
from thermocouples, resistors, and analog voltage/current.
Different sensors can be designated to each channel.
Ex.) CH1 input type = KCA.H, CH2 input type = JIC.H
Group Parameter Setting range Factory default Unit
Initial Setting Group Input Type See 6-1-1 K(CA).H -
When input types are modified, the high-limit and low-limit
setting values of SV are automatically changed to max/min
values of operational temperature range of the modified input
type. You must reset these values. (SV, Multi SV No, SV-0 to
SV-3 and input bias are initialized.) However, measurement
units remain the same.
If the measured value is out of the input range, the loader
program displays HHHH (high-limit), LLLL (low-limit) and
displays OPEN when the sensor is not connected.
6.1.3 Temperature Unit Settings for Input Temperature
Sensor
When selecting the temperature sensor input options, you can set the desired units of
operation temperature/display temperature.
Group Parameter Range Factory Default Unit
Initial Setting Group Unit , -
When modifying the temperature units, setting values of the related
parameters remain the same as the existing values, and SV, Multi SV
No., SV-0 to SV-3, SV high-limit/low-limit, and input bias will be
initialized.
