Autonics TM4 Series User Manual

6 Parameter Settings and Functions
© Copyright Reserved Autonics Co., Ltd. 45
6 Parameter Settings and
Functions
6.1 Input
6.1.1 Input Type and Temperature Range
Input Type No.
Decimal
Point
Indicator
Temperature
range (℃)
Temperature
range (℉)
Thermoco
uples
(Thermo-
Couple)
K(CA)
0 1 K(CA).H -200 ~ 1350 -328 ~ 2462
1 0.1 K(CA).L -200.0 ~ 1350.0 -328.0 ~ 2462.0
J(IC)
2 1 J(IC).H -200 ~ 800 -328 ~ 1472
3 0.1 J(IC).L -200.0 ~ 800.0 -328.0 ~ 1472.0
E(CR)
4 1 E(CR).H -200 ~ 800 -328 ~ 1472
5 0.1 E(CR).L -200.0 ~ 800.0 -328.0 ~1472.0
T(CC)
6 1 T(CC).H -200 ~ 400 -328 ~ 752
7 0.1 T(CC).L -200.0 ~ 400.0 -328.0 ~ 752.0
B(PR) 8 1 B(PR) 0 ~ 1800 32 ~ 3272
R(PR) 9 1 R(PR) 0 ~ 1750 32 ~ 3182
S(PR) 10 1 S(PR) 0 ~ 1750 32 ~ 3182
N(NN) 11 1 N(NN) -200 ~ 1300 -328 ~ 2372
C(TT)
※
1
12 1 C(TT) 0 ~ 2300 32 ~ 4172
G(TT)
※
2
13 1 G(TT) 0 ~ 2300 32 ~ 4172
L(IC)
14 1 L(IC).H -200 ~ 900 -328 ~ 1652
15 0.1 L(IC).L -200.0 ~ 900.0 -328.0 ~ 1652.0
U(CC)
16 1 U(CC).H -200 ~ 400 -328 ~ 752
17 0.1 U(CC).L -200.0 ~ 400.0 -328.0 ~ 752.0
Platinel II 18 1 PLII 0 ~ 1400 32 ~ 2552
Platinum
Resistance
Temperatu
re Detector
(RTD)
JPt100 Ω
19 1 JPt100.H -200 ~ 600 -328 ~ 1112
20 0.1 JPt100 .L -200.0 ~ 600.0 -328.0 ~ 1112.0
DPt100 Ω
21 1 DPt100.H -200 ~ 600 -328 ~ 1112
22 0.1 DPt100. L -200.0 ~ 600.0 -328.0 ~ 1112.0
※1: C(TT): Same temperature sensor as former W5 (TT).
※2: G(TT) : Same temperature sensor as former W (TT).
 Temperature sensors convert subject temperature to electrical signals for the
temperature controller, allowing it to control output.
 SV (Setting Value) can only be set within the input range.
