Autonics TM4 Series - Temperature Control Examples

5 Preparation and Startup
42 © Copyright Reserved Autonics Co., Ltd.
5.3 Temperature Control Examples
5.3.1 Single Modules
5.3.1.1 TM4-N2RB Model (relay output)
 Note 1) Using SCM-US enables only setting parameter. To monitor and control
temperature requires the additional 24VDC power supply.
Do not connect SCM-US and RS485 communications cables at the
bottom at the same time.
