5 Preparation and Startup
© Copyright Reserved Autonics Co., Ltd. 43
5.3.1.2 TM4-N2SB Model (SSR output)
Note1) Using SCM-US enables only setting parameter. To monitor and control
temperature requires the additional 24VDC power supply.
Do not connect SCM-US and RS485 communications cables at
the bottom at the same time.
Use an isolated type SSR.
To Next Page
