Autonics TM4 Series - Module Expansion

4 Connections and block diagram
38 © Copyright Reserved Autonics Co., Ltd.
4.2.4 Module Expansion
When using the bottom power supply/communication connection terminal (Port B), up to
31 modules can be connected at the same time.
Maximum required power = 31 X 5 W = 155 W
When connecting several module sets (31 modules or less), each module set requires
separate power supply.
