3 Dimensions
© Copyright Reserved Autonics Co., Ltd. 31
(2) For multiple modules
1) Installation method
① Pull each Rail Lock switch up and down.
② Mount the module body to the DIN rail and then push the rail lock in.
2) Removal method
① Pull each Rail Lock switch up and down.
② Remove the body from the DIN rail.
