Avaya C360 Layer 3 Features

174 Installation and Configuration Guide Avaya C360 Multilayer Stackable Switches, version 4.5

Specify the type of

authentication used in RIP

Version 2 packets

ip rip authentication mode

Set the authentication string

used on the interface

ip rip authentication key

Specify the RIP timers values timers basic

In order to... Use the following command...
