C360 Rear Panel

Issue 2 July 2005 37

C360 Rear Panel

The C360 rear panel contains a stacking module slot, AC power input and BUPS DC input.

Note:

Note: The C/S: and SW versions on your C360 switches may differ from those shown in

Figure 7

Figure 7: C360 Back Panel

Figure notes:

1. AC Input

2. BUPS DC Input

3. X360STK slot (shown covered)
